Introduction

visWall is the videowall controller, that’s designed to control high resolution videowall display in real-time. It fits for meeting room, command center, crisis management room, control room, monitoring room of organization that has many data in many representative formats

update history

visWall 1.5.1
15/03/2017

CROP function for WEB/URL input

improve CROP function for physical input

minor bug fixs

visWall 1.5.0
25/01/2017

support IP camera with special charactor in stream URL

support browser keep session when move/resize URL window

support Datapath activeSQX auto load-balance decodeing

minor bug fixs

visWall 1.4.6
30/06/2016

IE11 full support

add chrome engine for web view

bug fixs

visWall 1.4.0
21/12/2015

support Datapath activeSQX

support Datapath softSQX

optimized VNC connection

support self signed certificate for web view

increase not enlarge

visWall is the high-definition videowall system. It increases more pixel to display not just enlarge picture to be bigger same as the bundled feature of some videowall display products. visWall can drive maximum about 100Mega pixel 50 times higher than full HD display

work with high definition display

visWall is compatible with any high definition display devices with VGA, DVI or HDMI interface start from SVGA up to FullHD resolution. The devices can be professional or non-professional e.g. computer monitor, LCD TV, projector, LFD LCD, DLP projection cube. Also 4:3 , 16:9 or any aspect ratio.

Maximum configuration for native display output, visWall can has up to 48 native display* outputs. But for the system that has more than 48 monitors. visWall supports master/slave mode that gives possibility to have many hundreds monitors in the system from one single visWall server

System architecture

manage on the fly

visWall allows user to real-time control videowall by powerful user interface & tools.
⇒  Web application : use web browser to control e.g. IE, Firefox
⇒  Source library : keep your sources/input in folder structure, content preview and approve
⇒  Template : template, layout and snapshot can be saved and reload it later for quick launch with snapshot.
⇒  Layer : create layer (unlimited) on display area, and can be adjust size, position by drag & drop , support more than 8 windows in 1 screen.
⇒  playlist : create playlist to display on videowall layer
⇒  Snap to grid: visWall has virtual grid that help user to create template faster and more accurate
⇒  Ticker text : ticker text with logo can be created from viswall with different speed, font, size, direction (left, right, up, down)
⇒  External control: manage from external devices with RS232, LAN or wireless LAN from devices e.g. tablet PC, iPad
⇒  User management : new user can be created with different permission to the system. LDAP interfacing also available for single sign-on system
